IT化監視制御システムの構成技術
IT化監視制御システムの構成技術
カテゴリ: 技術報告
論文No: 1146
グループ名: 【D】産業応用部門
発行日: 2009/02/20
タイトル(英語): The Structural Technology of ICT-oriented Central Supervisory Control System
著者名: IT化監視制御技術協同研究委員会編
著者名(英語): Investigation R&D committee of ICT-oriented Central Supervisory and Control System
キーワード: IT化中央監視制御システム、ネットワーク、プロトコル/central supervisory and control system, network, communication protocol
要約(日本語): ビルデイングや工場の電気、空調、ユーテリテイなどの設備を中央監視室にて監視制御する中央監視制御システムがあり最近はビルデイングや工場の中枢システムとして重要視されている。中央監視制御システムは最新のIT技術をベースにTCP/IP等のIP通信ネットワークを基幹LANとして中央装置、サブコントローラ、フィールド装置からなる。またオープンなネットワーク接続性とプロトコルにより高信頼性にてマルチベンダー環境を容易に実現するビル、工場の近年のIT化監視制御システムの構成技術を内容を下記にて報告する。 (1) 監視制御システムの共通化、標準化の概要 (2) ネットワークの構成と信頼性 (3) オープン化プロトコルとシステム構成 (4) 遠隔監視制御と遠隔データ管理 (5) 無線方式による監視制御 (6) パネル構成と施工仕様
要約(英語): A central supervisory and control system is one of very important facilities for building/plant to maintain the building/plant automation and control functions constantly. This system is composed of central work station, sub controllers and field devices based on the latest ICT(Information and communication technology). This technical report describes on the structural technology of information-oriented central supervisory and control system for buildings and plants. The contents of this report are as follows; (1) The outline of the common technology of information-oriented central supervisory and control system; (2) The network structure and network reliability (3) The system structure and open communication protocol; (4) Remote control and remote data management by web application; (5) Wireless system; (6) The structure and installation of control boards
PDFファイルサイズ: 12,717 Kバイト
