配電用電線・架空ケーブルにおける耐環境性試験法の動向と課題
配電用電線・架空ケーブルにおける耐環境性試験法の動向と課題
カテゴリ: 技術報告
論文No: 1206
グループ名: 【B】電力・エネルギー部門
発行日: 2010/11/10
タイトル(英語): Trend and Issue of Environmental Resistance Test for Distribution Electric Wire and Overhead Cable
著者名: 配電用電線・ケーブル絶縁材料の耐環境性試験の技術動向調査専門委員会
著者名(英語): Investigating R&D Committee on Technical Trend of Environmental Resistance Test of Insulator Materials for Distribution Electric Wire and Cable
キーワード: 電線、ケーブル、屋外終端接続部、環境試験、規格/Electric Wire, Cable, Outdoor terminal joint, Environmental Resistance Test, Standard
要約(日本語): 配電用電線、架空ケーブル及び屋外終端接続部は、絶縁体やシースが屋外に暴露されるため、環境ストレスの影響が劣化の進行を左右する。一方、近年は、設備更新の機会が少なく、設備が高経年化しており、環境ストレスの蓄積による影響が懸念されている。よって、使用期間に受ける環境ストレスを評価できる環境試験の開発が望まれている。しかし現状は、各種規格の試験方法や判定基準の根拠に対する説明及び現行規格に適合した用品類に対する使用条件下での劣化状況の把握は十分とは言えない。このため、配電用電線、架空ケーブル及び屋外終端接続部に関係する規格類(保安安全法規、JIS、JEC規格、JCAA規格、JCS規格、電力用規格、ユーザ独自規格等)及び、規格制定や改正に関係する電気学会技術報告や電気協同研究を幅広く調査した。本報告書では、現在の各種規格の規格値や試験方法の考え方及び現在の規格に適合した設備の劣化状況等を取り纏めている。
要約(英語): As for distribution wire, overhead cable, and outdoor terminal joints, since their insulators and sheathes are exposed outdoors, the environmental stress affects their deterioration progress. Recently, there being few opportunity of equipment replacement, the numbers of old equipments on their field have been increasing, and so the influence of the environmental stress accumulation has been anticipated. Therefore it is hoped for the development of the environmental resistance test to be able to assess the stress received in the periods of being used. However, at present there is not enough explanation about test procedure and criteria. Environmental deterioration states of the equipments which were not necessarily understood. As a result, this committee widely investigated some standards of distribution electric wire, overhead cable and outdoor terminal joints such as electrical safety laws, Japanese Industrial standards (JIS), Japanese Electrotechnical Committee (JEC), Japan Power Cable Accessories Association (JCAA), Japanese Cable Maker's Association Standard (JCS), Power Electric Standards, and the user’s original standards etc. Additionally, Electrical Engineers Technical Reports published by Institute of Electrical Engineers of Japan and Electric Technology Research Association, related to establishment and revision of standards, were also investigated. In this report all these matters were summarized.
PDFファイルサイズ: 5,931 Kバイト
