屋外用ポリマー絶縁材料の表面機能と長期性能

屋外用ポリマー絶縁材料の表面機能と長期性能

通常価格 ¥3,300 JPY
通常価格 セール価格 ¥3,300 JPY
セール 売り切れ
税込

カテゴリ: 技術報告

論文No: 1325

グループ名: 【A】基礎・材料・共通部門

発行日: 2014/12/10

タイトル(英語): Surface Properties and Long-term Performance of Polymeric Insulating Materials for Outdoor Use

著者名: 屋外用ポリマー絶縁材料の表面機能と長期性能調査専門委員会

著者名(英語): Investigating R&D Committee on Surface Properties and Long-term Performance of Polymeric Insulating Materials for Outdoor Use

キーワード: ポリマーがいし、屋外絶縁、シリコーンゴム、撥水性、長期性能/Polymeric insulator, outdoor insulation, silicone rubber, hydrophobicity, long-term performance

要約(日本語): シリコーンゴムなどの屋外用ポリマー絶縁材料を用いたポリマーがいしは、磁器がいしに比較して、作業性や耐汚損性能、耐震性に優れることから、近年、急速にその適用が拡大している。しかし、ポリマーがいしは、構成材に有機材料を用いることから、その材料劣化や寿命に関する技術課題の解明が不可欠である。これまで、ポリマー材料の撥水性と放電形態の相関や材料劣化量と放電電気量の関係、さらにはその性能評価技術や試験法などについて検討が進められてきた。しかし、シリコーンゴムの表面撥水性挙動の定量的評価や放電・劣化特性への影響については、依然、未解明な部分も多く、がいし材料としての長期性能評価手法が明確になっていないなどの課題も抽出された。そこで本委員会では、屋外用ポリマー絶縁材料に関わる最新の技術開発動向や、ポリマーがいし製品としての要求性能と材料性能の関係、さらには材料性能の評価技術に関する検討状況を調査した。また、ポリマーがいし表面の放電・劣化現象の解明と長期性能評価に向け、残された技術課題の抽出・整理を行った。具体的には、屋外用ポリマー絶縁材料の撥水性挙動が放電・劣化特性に与える影響、表面撥水性挙動の定量的評価、実使用環境でのポリマー絶縁材料の表面特性と放電・劣化現象などについて、調査研究活動より得られた成果を示した。

要約(英語): Application of polymeric insulators has been expanded in the field of power supply and distribution system all over the world. Compared to porcelain insulators, however, polymeric insulators have been demanded to solve the challenging subjects on a long-term reliability and diagnosis techniques in the real application field. In 2006, the investigation committee started to clarify the relation between surface properties and long-term performance of polymeric insulating materials. Several kinds of plate type specimens made of silicone rubber were shared to the members, and time variation of surface hydrophobicity, discharge phenomena and degradation properties of the materials were investigated using their own advancing measurement techniques. The main subjects of the investigation committee were as follows,
1. Relation between hydrophobicity and discharge phenomena, and degradation of polymeric insulating materials for outdoor use.
2. Evaluation of time variation of hydrophobicity of silicone rubbers.
3. Surface properties and electrically induced degradation in service conditions.
4. Artificial aging test methods for evaluation of long-term reliability.
5. Functional and dielectric properties of polymeric insulating materials.

PDFファイルサイズ: 6,077 Kバイト
