方形コイル系を用いた渦電流速度計の特性解析

カテゴリ: 論文誌(論文単位)

グループ名: 【A】基礎・材料・共通部門

発行日: 2013/08/01

タイトル(英語): Analysis of an Eddy Current Speed Meter by Rectangular Coil System

著者名: 板谷　年也（鈴鹿工業高等専門学校），石田　浩一（徳山工業高等専門学校），田中　章雄（宇部工業高等専門学校），武平　信夫（徳山工業高等専門学校），山本　節夫（山口大学大学院理工学研究科）

著者名(英語): Toshiya Itaya (Suzuka National College of Technology), Koichi Ishida (Tokuyama College of Technology), Akio Tanaka (Ube National College of Technology), Nobuo Takehira (Tokuyama College of Technology), Setsuo Yamamoto (Yamaguchi University, Graduate School of Science and Engineering)

キーワード: 渦電流速度計，方形コイル，速度特性，非破壊検査，解析的手法，二重フーリエ変換　　eddy current speed meter，rectangular coil，speed characteristics，nondestructive testing，analytical method，double fourier transform

要約(英語): Eddy current measurement technology are widely used in instruments such as displacement meters, vibration meters, and non-destructive testing equipment. In this paper, we proposes eddy current speed meter using a rectangular coil and clarifies its speed characteristics using an analytical method. A rectangle has a shape effect not present in a circle and an improvement in characteristics due to the coil system aspect ratio and also improvement in the flux utilization and miniaturization of the sensor can be expected. Therefore, after verifying the validity of the analytical solution through experiments, the speed characteristics are calculated for a case in which the parameters relating to the moving conductor-slab are varied and that in which the coil system aspect ratio is varied. In addition, essential documentation for the optimum design of rectangular coil eddy current speed meter is obtained.

本誌: 電気学会論文誌A（基礎・材料・共通部門誌） Vol.133 No.8 （2013）

本誌掲載ページ: 416-423 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejfms/133/8/133_416/_article/-char/ja/
