異なる純度のO2中における負イオン移動度とH2O濃度の同時測定
異なる純度のO2中における負イオン移動度とH2O濃度の同時測定
カテゴリ: 論文誌(論文単位)
グループ名: 【A】基礎・材料・共通部門
発行日: 2018/02/01
タイトル(英語): Simultaneous Measurement of Negative Ion Mobility and H2O Concentration in Different Purities O2
著者名: 奥山 由(苫小牧工業高等専門学校),鈴木 進(千葉工業大学),伊藤 晴雄(千葉工業大学)
著者名(英語): Yui Okuyama (National Institute of Technology, Tomakomai College), Susumu Suzuki (Chiba Institute of Technology), Haruo Itoh (Chiba Institute of Technology)
キーワード: 負イオン移動度,H2O濃度,不純物,ガス純度,高気圧イオンドリフトチューブ negative ion mobility,H2O concentration,impurities,gas purities,high pressure ion drift tube
要約(英語): In this study, we carried out a simultaneous measurement of the negative ion mobility and the H2O concentration in different purities O2 using a high pressure ion drift tube for an investigation on effects of impurities. We used four different purities O2 as ultrahigh-purity (99.99995% with a gas purifier), high-purity 1 (99.99995%), high-purity 2 (99.9999%) and low-purity (99.9%). The H2O concentration in ultrahigh-purity O2 through the chamber equipped the ion drift tube was monitored between 15 to 100 ppb although the gas purifier could be removed the H2O concentration less than 100 ppt because of an outgassing from the inner surfaces of the chamber, ion drift tube and so on. In contrast, the ion mobility was observed as a constant value of 2.39 cm2/V・s as O4-. Then, a mobility 2.31 cm2/V・s was observed in high-purity 1 and 2 of which the H2O concentrations were 500 and 550 ppb, respectively. An interest result was found in low-purity O2 that is two mobilities 2.41 and 2.50 cm2/V・s corresponding to CO4- and N2O2- were measured in the H2O concentration between 400 to 580 ppb. One of the reasons considered as the effects of CO2 and N2 contained in O2.
本誌: 電気学会論文誌A(基礎・材料・共通部門誌) Vol.138 No.2 (2018) 特集:放電研究の最新動向
本誌掲載ページ: 50-56 p
原稿種別: 論文/日本語
電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejfms/138/2/138_50/_article/-char/ja/
