Development and Characteristics of Pulsed Radiation Source Generated by Electron Beam Irradiation using Intense Pulsed Power Generator

カテゴリ: 論文誌(論文単位)

グループ名: 【A】基礎・材料・共通部門

発行日: 2019/10/01

タイトル(英語): Development and Characteristics of Pulsed Radiation Source Generated by Electron Beam Irradiation using Intense Pulsed Power Generator

著者名: Kenji Kashine (National Institute of Technology, Kagoshima College), Fumihiro Tamura (National Institute of Technology, Nagaoka College), Takashi Kikuchi (Nagaoka University of Technology), Weihua Jiang (Nagaoka University of Technology)

著者名(英語): Kenji Kashine (National Institute of Technology, Kagoshima College), Fumihiro Tamura (National Institute of Technology, Nagaoka College), Takashi Kikuchi (Nagaoka University of Technology), Weihua Jiang (Nagaoka University of Technology)

キーワード: radiation source，electron beam，pulsed power generator，radiation energy measurement

要約(英語): Development and characteristic investigation of a pulsed radiation source which is generated by irradiating an electron beam to aluminum target was performed. An NaI(Tl) scintillation detector and a shaping amplifier were used for measuring the radiation energy. From the actual experiment, the radiation energy per unit area was estimated to be 12 MeV/mm2 for one shot of electron beam irradiation. A CCD camera was used for estimating the radiation areal density. Number of white dots which considerable to effect caused by the radiation were existed in an acquired image. The areal density of white dots was obtained to be approximately 6000 dots/mm2 at the behind of 3 m from the radiation source.

本誌: 電気学会論文誌A（基礎・材料・共通部門誌） Vol.139 No.10 （2019） 特集：高繰り返しパルスパワー電源の最新技術と応用

本誌掲載ページ: 435-436 p

原稿種別: 研究開発レター／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejfms/139/10/139_435/_article/-char/ja/
