反射鏡を用いた指向制御可能な超音波センサシステム

カテゴリ: 論文誌(論文単位)

グループ名: 【A】基礎・材料・共通部門

発行日: 2019/11/01

タイトル(英語): A Directional Controllable Ultrasonic Sensor System using a Reflecting Mirror

著者名: 上田　拓矢（日本大学大学院理工学研究科電子工学専攻），佐伯　勝敏（日本大学大学院理工学研究科電子工学専攻），根口　純一（日本電子工学（株）），應後　剛（日本電子工学（株）），織田　武浩（日本電子工学（株））

著者名(英語): Takuya Ueda (Department of Electric Engineering, Graduate School of Science and Technology, Nihon University), Katsutoshi Saeki (Department of Electric Engineering, Graduate School of Science and Technology, Nihon University), Jyunichi Neguchi (Nihon Denshi Kougaku Corporation), Takeshi Ohgo (Nihon Denshi Kougaku Corporation), Takehiro Orita (Nihon Denshi Kougaku Corporation)

キーワード: 段差型主反射鏡，2焦点凹凸型副反射鏡，送受信一体型超音波センサ，指向制御　　multi-layer main reflector，dual focus concavoconvex sub-reflector，integrated transmission / reception ultrasonic sensor，directional control

要約(英語): In recent years, in order to prevent conflicts between heavy machinery and people, development of a system using supersonic sensing with high reception feeling and direction controllable has been performed. In the past, we investigated directional control of ultrasonic waves using a multilayer main reflector and a concavo-convex curve sub-reflector. In this paper, we propose dual focal concavo-convex curve sub-reflector and a multilayer main reflector. As a result, the size was reduced by half compared with the conventional reflector, and the detection distance of 4 m or more became possible. It is clarified that directivity control is possible in the range of +38°, -34° to +50°, -58°.

本誌: 電気学会論文誌A（基礎・材料・共通部門誌） Vol.139 No.11 （2019） 特集Ⅰ：電気電子工学関連分野における教育フロンティア　特集Ⅱ：イノベーションを創出する最新の計測技術2019

本誌掲載ページ: 527-532 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejfms/139/11/139_527/_article/-char/ja/
