強磁場のための磁化方向

カテゴリ: 論文誌(論文単位)

グループ名: 【A】基礎・材料・共通部門

発行日: 2021/09/01

タイトル(英語): Magnetized Direction for Strong Magnetic Field

著者名: 西村　一寛（国立高専機構鈴鹿工業高等専門学校）

著者名(英語): Kazuhiro Nishimura (National Institute of Technology, Suzuka College)

キーワード: 強磁場配列，ハルバッハ配列，磁場源，永久磁石　　strong magnetic field allays，Halbach allays，magnetic field source，permanent magnet

要約(英語): The magnetization direction in which the magnetic field becomes the strongest on one axis is derived by the spherical coordinate system. It was found that the magnetic field was strongest at the top and bottom on the axis, and was weakest at the 0 points on the axis. Therefore, it is indicated that there is an optimal division instead of equality when segmenting. Based on the direction of magnetization of the spherical coordinate system, the direction applied in the cylindrical coordinate system and the orthogonal coordinate system is shown. For Halbach sphere and Halbach cylinder, the magnetic field is shown. This magnetization direction is the guiding principle of the design of the magnetic field source, for example, magnetic drag targeting systems and MRI devices. This can be applied not only to the design of magnetic field sources of permanent magnets, but also to the design of electromagnets and superconducting electromagnets.

本誌: 電気学会論文誌A（基礎・材料・共通部門誌） Vol.141 No.9 （2021） 特集：イノベーションを創出する最新の計測技術2021

本誌掲載ページ: 514-518 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejfms/141/9/141_514/_article/-char/ja/
