モールド絶縁系における微小空気ギャップの絶縁特性(2)―MGM,MGI電極系の部分放電挙動―

モールド絶縁系における微小空気ギャップの絶縁特性(2)―MGM,MGI電極系の部分放電挙動―

通常価格 ¥770 JPY
通常価格 セール価格 ¥770 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2013/02/01

タイトル(英語): Insulation Behavior of Small-air-gap for the Molded-insulation System (2)―Partial Discharge Behavior of MGM and MGI Systems―

著者名: 東山 雅一(東芝産業機器製造(株)),鈴木 勇人(東芝産業機器製造(株)),広瀬 達也((株)東芝),前田 照彦((株)東芝),中村 修平(三重大学),梅村 時博(三重大学),小迫 雅裕(九州工業大学),匹田 政幸(九州工業大学)

著者名(英語): Masakazu Higashiyama (Toshiba Industrial Products Manufacturing Co.), Hayato Suzuki (Toshiba Industrial Products Manufacturing Co.), Tatsuya Hirose (Toshiba Co.), Teruhiko Maeda (Toshiba Co.), Shuhei Nakamura (Mie University), Tokihiro Umemura (Mie University), Masahiro Kozako (Kyushu Institute of Technology), Masayuki Hikita (Kyushu Institute of Technology)

キーワード: モールド変圧器,部分放電,ストリーマ,グロー放電,初期電子,Paschen則  cast-resin transformer,partial discharge,streamer,glow-like discharge,initiating electron,Paschen's law

要約(英語): Insulation discharge behavior of small-air-gap for the molded insulation system has been investigated in view of the Paschen curve. Two electrode systems Metal-Gap-Metal (MGM) and Metal-Gap-Insulator (MGI) were employed as the test samples. It was found that the Vs (breakdown voltage of the air gap) in the Paschen left region was determined in terms of glow-like discharge with slow micro-second order of discharge-current probably due to the ionic current for both MGM and MGI electrode systems. In the minimum and right regions of the Paschen curve for MGM, the partial discharge showed the streamer-like discharge current with relatively short rise-time and short discharge-duration. For the MGI-electrode system, however, the discharge type was found to lie in all glow-like discharge with small discharge current. The glow-like discharge, Townsend and streamer discharges were also recognized by the high speed CCD camera photographs.

本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.133 No.2 (2013) 特集:デジタルグリッドが拓く新しい電力流通の姿

本誌掲載ページ: 203-209 p

原稿種別: 論文/日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/133/2/133_203/_article/-char/ja/
