固有TRV測定における接線と規約値算出の検討
固有TRV測定における接線と規約値算出の検討
カテゴリ: 論文誌(論文単位)
グループ名: 【B】電力・エネルギー部門
発行日: 2013/11/01
タイトル(英語): Investigation of Tangential Line and Prospective Values for TRV Measurements
著者名: 腰塚 正((株)東芝),工藤 喜悦((株)東芝),中本 哲哉((株)東芝),萩森 英一(東京大学),伊吹 恒二(東京大学),池田 久利(東京大学)
著者名(英語): Tadashi Koshizuka (Toshiba Co.), Kietsu Kudo (Toshiba Co.), Tetsuya Nakamoto (Toshiba Co.), Eiichi Haginomori (The University of Tokyo), Koji Ibuki (The University of Tokyo), Hisatoshi Ikeda (The University of Tokyo)
キーワード: 過渡回復電圧,固有値,不確かさ transient recovery voltage,prospective TRV,uncertainty
要約(英語): The prospective transient recovery voltage (TRV) at current interruption for circuit breakers should be measured by using ideal circuit breaker. Prospective values of the TRV are obtained by drawing tangential line to the TRV waveform. But, it is difficult to draw the tangential line on the four parameters TRV waveform automatically by computer software.This paper shows the new method to draw the tangential line on the four parameters TRV waveform. It is easy to draw the tangential line on the TRV waveform by simple waveform transform process. This method is easy to code to the computer software. Also, it was investigated to decide the current zero at prospective TRV measurements.
本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.133 No.11 (2013) 特集:開閉保護技術
本誌掲載ページ: 826-831 p
原稿種別: 論文/日本語
電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/133/11/133_826/_article/-char/ja/
