フラックスゲート直流漏電センサにおける温度特性の補正方式に関する研究
フラックスゲート直流漏電センサにおける温度特性の補正方式に関する研究
カテゴリ: 論文誌(論文単位)
グループ名: 【B】電力・エネルギー部門
発行日: 2013/11/01
タイトル(英語): Study on Temperature Characteristics Compensation Method of a Flux-gate DC Earth Leakage Current Sensor
著者名: 渡邊 佳正(三菱電機(株)先端技術総合研究所),西沢 博志(三菱電機(株)先端技術総合研究所),仲嶋 一(三菱電機(株)先端技術総合研究所),鹿井 正博(三菱電機(株)先端技術総合研究所),平位 隆史(三菱電機(株)先端技術総合研究所)
著者名(英語): Yoshimasa Watanabe (Advanced Technology R&D Center, Mitsubishi Electric Corp.), Hiroshi Nishizawa (Advanced Technology R&D Center, Mitsubishi Electric Corp.), Hajime Nakajima (Advanced Technology R&D Center, Mitsubishi Electric Corp.), Masahiro Shikai (Advanced Technology R&D Center, Mitsubishi Electric Corp.), Takashi Hirai (Advanced Technology R&D Center, Mitsubishi Electric Corp.)
キーワード: フラックスゲート,漏電センサ,フーリエ変換,基本波成分,補正,温度特性 flux-gate,earth leakage current sensor,Fourier transform,first harmonic,compensation,temperature characteristics
要約(英語): This study focused on the development of a DC earth leakage current sensor comprising a flux-gate. Although a flux-gate leakage current sensor has conventionally used, the fluctuation of sensitivity due to the variation of temperature occurs up to approximately ±15%. The compensation method of the temperature characteristic by taking advantage of the detected voltage of first harmonic at R. T. (298K) under the leakage current of 0mA enabled us to reduce the fluctuation under ±10%.
本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.133 No.11 (2013) 特集:開閉保護技術
本誌掲載ページ: 851-857 p
原稿種別: 論文/日本語
電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/133/11/133_851/_article/-char/ja/
