送電線再閉路時における残留電圧予測法の検討

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2013/11/01

タイトル(英語): Study for Voltage Prediction on Line Reclosing

著者名: 香山　治彦（三菱電機（株）系統変電システム製作所），森　智仁（三菱電機（株）系統変電システム製作所），山本　綾（三菱電機（株）系統変電システム製作所），亀井　健次（三菱電機（株）系統変電システム製作所），伊藤　弘基（三菱電機（株）電力・産業システム事業本部），小林　翔一（三菱電機（株）先端技術総合研究所），蔦田　広幸（三菱電機（株）先端技術総合研究所），鹿井　正博（三菱電機（株）先端技術総合研究所）

著者名(英語): Haruhiko Kohyama (T&D Systems Center, Mitsubishi Electric Corp.), Tomohito Mori (T&D Systems Center, Mitsubishi Electric Corp.), Aya Yamamoto (T&D Systems Center, Mitsubishi Electric Corp.), Kenji Kamei (T&D Systems Center, Mitsubishi Electric Corp.), Hiroki Ito (Energy&Industrial Systems Group, Mitsubishi Electric Corp.), Shoichi Kobayashi (Advanced Technology R&D Center, Mitsubishi Electric Corp.), Hiroyuki Tsutada (Advanced Technology R&D Center, Mitsubishi Electric Corp.), Masahiro Shikai (Advanced Technology R&D Center, Mitsubishi Electric Corp.)

キーワード: 送電線，リアクトル補償線路，残留電圧，開閉極位相制御，再閉路，ガス遮断器　　transmission line，reactor compensated line，residual voltage，controlled switching，reclosing，gas circuit breaker

要約(英語): The practical prediction method was studied and evaluated for transmission line voltage after circuit breaker open, where d.c. voltage remains. In case of reactor compensated lines, oscillating voltage appears with a frequency determined by line to earth capacitance and reactor at the end of line. As the line side voltage wave also includes subsidiary oscillation by phase to phase capacitance and dumps by charge leakage along supporting insulators, high-speed processor is required to predict the voltage wave by fitting or pattern recognition methods. Limited parameters such as line voltage frequency and its phase angle make very fast wave analysis feasible within 0.1 seconds using general purpose processors. Controlled reclosing of transmission line utilizing the prediction method is evaluated by numerical analysis to reduce switching overvoltage satisfactory.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.133 No.11 （2013） 特集：開閉保護技術

本誌掲載ページ: 875-881 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/133/11/133_875/_article/-char/ja/
