開放管路を有する容器内におけるアーク短絡故障時の圧力上昇・伝搬特性

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2013/11/01

タイトル(英語): Pressure Rise and Propagation Phenomena due to Fault Arc in the Container with Opened Pipe

著者名: 宮城　吏（（一財）電力中央研究所 電力技術研究所），田中　慎一（（一財）電力中央研究所 電力技術研究所），岩田　幹正（（一財）電力中央研究所 電力技術研究所），天川　正士（（一財）電力中央研究所 電力技術研究所）

著者名(英語): Tsukasa Miyagi (Electric Power Engineering Research Lab., Central Research Institute of Electric Power Industry (CRIEPI)), Shin-ichi Tanaka (Electric Power Engineering Research Lab., Central Research Institute of Electric Power Industry (CRIEPI)), Mikimasa Iwata (Electric Power Engineering Research Lab., Central Research Institute of Electric Power Industry (CRIEPI)), Tadashi Amakawa (Electric Power Engineering Research Lab., Central Research Institute of Electric Power Industry (CRIEPI))

キーワード: アーク電流，圧力，銅，管路，開放，短絡故障　　arc current，pressure，copper，pipe，open，short circuit fault

要約(英語): This paper describes experimental and analytic studies on pressure rise and propagation phenomena due to high current arcs in a container with opened pipes. The shape of experimental container is decided taking into account of underground common ducts. First, the arcs were ignited in the container with varying diameter D and length L of the opened pipes under the condition of arc current of 4 to 12.5kA and the arc duration of 0.1s. Based on measured waveforms, the maximum value of pressure rise Pmax and the pressure oscillation frequency Posc were obtained. As the result, it emerged that there is a tendency that Pmax becomes high with lessened D and elongated L. Moreover, D has a much greater impact on Pmax. And it emerged that the tendency of Posc with changing D and L can be explained by Helmholtz resonance approximately. Secondly, CFD model for the container with opened pipe was developed based on the experimental results, and simulations were carried out. Consequently, simulation results were found to correspond to the experimental pressure rise.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.133 No.11 （2013） 特集：開閉保護技術

本誌掲載ページ: 888-894 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/133/11/133_888/_article/-char/ja/
