ビル直撃雷による接地線間過電圧発生メカニズムの考察

ビル直撃雷による接地線間過電圧発生メカニズムの考察

通常価格 ¥770 JPY
通常価格 セール価格 ¥770 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2020/03/01

タイトル(英語): Consideration of Generating Mechanism of the Overvoltage between the Ground Wires in a Building Struck Directly by Lightning

著者名: 小木曽 将人(名古屋工業大学),小森 駿矢(名古屋工業大学),安井 晋示(名古屋工業大学),山本 達也((株)トーエネック技術研究開発部),小林 浩((株)トーエネック技術研究開発部)

著者名(英語): Masato Ogiso (Nagoya Institute of Technology), Syunya Komori (Nagoya Institute of Technology), Shinji Yasui (Nagoya Institute of Technology), Tatsuya Yamamoto (Reserch and Development Div., Toenec Corporation), Hiroshi Kobayashi (Reserch and Development Div., Toenec Corporation)

キーワード: 接地線,電位差,直撃雷,ビル,電位分布  ground wires,potential difference,direct lightning strike,building,potential distribution

要約(英語): We investigated the mechanism by which a lightning strike generates overvoltage at a building's distribution board. We analyzed the overvoltage using VSTL electromagnetic analysis software and constructed a simplified mathematical model for calculating the overvoltage. The results confirmed that the overvoltage generated at the distribution board is not affected by the arrangement of the ground wires. The overvoltage is instead dominated by the potential difference between the ground electrodes, which is determined by the potential distribution in the surrounding ground. The overvoltage was calculated by the potential interferometry at steady state of the ground potential distribution. The calculated results of the overvoltages differed within ±10% from the analyzed results.

本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.140 No.3 (2020) 特集:未来社会創造に向けた超電導バルク材の挑戦

本誌掲載ページ: 198-203 p

原稿種別: 論文/日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/140/3/140_198/_article/-char/ja/
