真空バルブの電流零点後におけるアノード電極表面の温度分布
真空バルブの電流零点後におけるアノード電極表面の温度分布
カテゴリ: 論文誌(論文単位)
グループ名: 【B】電力・エネルギー部門
発行日: 2021/11/01
タイトル(英語): Measurement of Transient Temperature Distribution at Anode Surface After Current Zero in Vacuum Interrupter
著者名: 大坊 昂(東芝インフラシステムズ(株)インフラシステム技術開発センター),丹羽 芳充(東芝インフラシステムズ(株)インフラシステム技術開発センター),浅利 直紀(東芝インフラシステムズ(株)インフラシステム技術開発センター),坂口 亙(東芝インフラシステムズ(株)インフラシステム技術開発センター),佐々木 遥(東芝インフラシステムズ(株)インフラシステム技術開発センター),吉田 剛(東芝インフラシステムズ(株)インフラシステム技術開発センター)
著者名(英語): Akira Daibo (Infrastructure Systems Research and Development Center, Toshiba Infrastructure Systems & Solutions Corporation), Yoshimitsu Niwa (Infrastructure Systems Research and Development Center, Toshiba Infrastructure Systems & Solutions Corporation),
キーワード: 遮断器,真空バルブ,真空アーク,電極温度 circuit breaker,vacuum interrupter,vacuum arc,anode temperature
要約(英語): In vacuum interrupters, an insulation ability is degraded immediately after high current interruption, because of thermal electrons, metal vapors, and residual plasma. Thermal electrons and metal vapors are produced from the electrode surface, which is heated by the arc between electrodes. Therefore the electrode temperature affects its insulation ability. It is important to measure the transient of temperature distribution at anode surface after current zero, for explication of interruption phenomenon in vacuum. Two color pyrometer method with a high-speed camera for temperature measurement of electrode in vacuum was applied. Temperature of Cu-Cr spiral test electrode was measured after current zero by its method and time change of temperature distribution at anode surface was obtained. Also, relationship between interruption current and time change of anode temperature was investigated.
本誌: 電気学会論文誌B(電力・エネルギー部門誌) Vol.141 No.11 (2021) 特集:開閉保護技術
本誌掲載ページ: 712-717 p
原稿種別: 論文/日本語
電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/141/11/141_712/_article/-char/ja/
