200kV直流架空送電線下における直流磁界の評価

カテゴリ: 論文誌(論文単位)

グループ名: 【B】電力・エネルギー部門

発行日: 2022/11/01

タイトル(英語): Assessment of DC Magnetic Fields under a 200kV DC Overhead Transmission Line

著者名: 椎名　健雄（（一財）電力中央研究所），宮島　清富（（一財）電力中央研究所），椙本　一登（東京電力パワーグリッド（株）），松野　秀明（東京電力パワーグリッド（株））

著者名(英語): Takeo Shiina (Central Research Institute of Electric Power Industry), Kiyotomi Miyajima (Central Research Institute of Electric Power Industry), Kazuto Sugimoto (TEPCO Power Grid, Incorporated), Hideaki Matsuno (TEPCO Power Grid, Incorporated)

キーワード: 直流送電，架空送電線，電気環境，磁界，ビオ・サバールの法則_x000D_　　DC power transmission，overhead transmission line，electrical environment，magnetic field，Biot-Savart law

要約(英語): DC magnetic fields under the Hida-Shinano 200kV DC overhead transmission line were assessed by measurements. The DC magnetic fields observed under the DC overhead transmission line are a superposition of the geomagnetic field and that generated by the DC line current. In this study, the DC magnetic fields generated by the transmission line were obtained by a vector subtraction of the geomagnetic field from the total DC magnetic field. The measured geomagnetic field was 47.1μT and the assessed magnetic fields from the line with a current of 2250A were from 3.8μT to 8.3μT depending on the operating condition of the DC transmission line.

本誌: 電気学会論文誌B（電力・エネルギー部門誌） Vol.142 No.11 （2022） 特集：気象情報の利活用に基づく新しい電力系統運用技術

本誌掲載ページ: 568-569 p

原稿種別: 研究開発レター／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejpes/142/11/142_568/_article/-char/ja/
