High-Sensitivity and Wide-Range CMOS Temperature Sensor Circuit

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2011/07/01

タイトル(英語): High-Sensitivity and Wide-Range CMOS Temperature Sensor Circuit

著者名: Koichi Tanno (Department of Electrical and Electronic Engineering, Faculty of Engineering, University of Miyazaki), Ryota Sakamoto (Department of Electrical and Electronic Engineering, Faculty of Engineering, University of Miyazaki), Hiroki Tamura (Department of Electrical and Electronic Engineering, Faculty of Engineering, University of Miyazaki)

著者名(英語): Koichi Tanno (Department of Electrical and Electronic Engineering, Faculty of Engineering, University of Miyazaki), Ryota Sakamoto (Department of Electrical and Electronic Engineering, Faculty of Engineering, University of Miyazaki), Hiroki Tamura (Department of Electrical and Electronic Engineering, Faculty of Engineering, University of Miyazaki)

キーワード: temperature sensor circuit，PTAT，high-sensitivity，wide-range，analog integrated circuit

要約(英語): In this paper, the architecture for high-sensitivity and wide-range CMOS temperature sensor circuits is presented. The proposed architecture consists of the PTAT circuit with the positive slope, the PTAT circuit with the negative slope and a subtractor. The concrete circuit based on the proposed architecture is designed, and evaluated through HSPICE with a set of device parameters of 0.18μm CMOS process. The simulations demonstrate a maximum temperature error of 2.3℃ and the maximum current consumption of 28.7μA under the condition that the temperature range is from -20℃ to 100℃, the sensitivity is 5.2mV/℃ and VDD=1.5V.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.131 No.7 （2011） 特集：平成22年電気学会電子・情報・システム部門大会

本誌掲載ページ: 1281-1286 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/131/7/131_7_1281/_article/-char/ja/
