乳児の吸啜時における舌-人工乳首接触力の計測に基づく舌運動解析の試み

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2015/11/01

タイトル(英語): Analysis of Tongue Movement based on Measurement of Tongue-Nipple Contact Force for Infant Sucking

著者名: 西 　恵理（摂南大学 理工学部），長松　有衣子（独立行政法人地域医療機能推進機構大阪病院 小児科），黒柳　裕一（高槻赤十字病院 小児内分泌科），武井　安津子（社会医療法人愛仁会高槻病院 新生児小児科），榎本　真宏（社会医療法人愛仁会高槻病院 新生児小児科），新川　拓也（大阪電気通信大学 医療福祉工学部）

著者名(英語): Eri Nishi (Department of Science and Engineering, Setsunan University), Yuiko Nagamatsu (Department of Pediatrics, Japan Community Health care Organization Osaka Hospital), Yuichi Kuroyanagi (Department of Pediatrics, Takatsuki Red Cross Hospital), Atsuko Takei (Department of Neonatology, Takatsuki General Hospital), Masahiro Enomoto (Department of Neonatology, Takatsuki General Hospital), Takuya Niikawa (Department of Biomedical Engineering, Osaka Electro-Communication University)

キーワード: 乳児，吸啜時，舌-人工乳首接触力，計測，舌運動解析　　infant，sucking，tongue-nipple contact force，measurement，analysis of tongue movement

要約(英語): The aim of this study is to analyse the mechanism of tongue movement in an infant during sucking. We directly measured the force applied on an artificial nipple using small built-in force sensors. Force sensors are cantilever structures with a thin stainless steel beam and an all-purpose foil strain gauge attached to the surface of the beam. The sensors are arranged at the tip, middle and base of the nipple to capture velocity of the tongue elevation. The signal, obtained from the force sensor running through a bridge circuit and amplifier, is A/D converted with a sampling frequency of 1kHz, and a 12bit quantization resolution is input to the PC via a USB port. The measurement data are displayed in a real-time graph on a monitor. Using this system, we continuously measured the force applied on an artificial nipple during effective and ineffective sucking in infants. We found differences between infants with and without established oral feeding with respect to phase difference and the maximum force applied to the nipple. Furthermore, the velocity of the tongue movement was calculated and showed differences between individual infants.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.135 No.11 （2015） 特集：電気関係学会関西連合大会

本誌掲載ページ: 1322-1327 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/135/11/135_1322/_article/-char/ja/
