グリッドバイアス正負遷移状態を考慮した小型三極真空管の高精度モデル

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2019/01/01

タイトル(英語): High Precision Model of Small Triode Tube Considering Grid-Bias Positive/Negative Transition State

著者名: 大下　栞（広島工業大学），竹本　香菜子（広島工業大学），濱崎　利彦（広島工業大学）

著者名(英語): Shiori Oshimo (Hiroshima Institute of Technology), Kanako Takemoto (Hiroshima Institute of Technology), Toshihiko Hamasaki (Hiroshima Institute of Technology)

キーワード: 三極真空管，SPICE，モデリング，空間電荷，非線形性，シミュレーション　　triode tube，SPICE，modeling，space charge，nonlinearity，simulation

要約(英語): We propose a unified high precision SPICE model miniature triode tube series. The model formula was devised by high precision measurement data of 12AX7, 12AU7, 12AY7, 12AT7. In the conventional model, the perveance value and the amplification factor, which are the basic parameters expressing the I-V characteristic, have been given respectively as a constant for each vacuum tube. We have found that these values are the modulation coefficient by operation conditions depending on the electrode shape. We proposed a new physical model incorporating the physical phenomena of space charge modulation including the threshold vicinity and positive grid bias. As a result, we succeeded for the first time to express the modulation of amplification factor with small signal characteristics parameters which enables to simulate the complicated non-linear behavior such as distortion property of amplifier.
