圧電トランスを用いた受動複素係数フィルタの一構成

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2019/01/01

タイトル(英語): Synthesis of a Passive Complex Coefficient Filter Using Piezoelectric Transformers

著者名: 矢浦　佑騎（筑波大学　システム情報工学研究科），庄野　和宏（筑波大学　システム情報工学研究科）

著者名(英語): Yuki Yaura (Graduate School of Systems and Information Engineering, University of Tsukuba), Kazuhiro Shouno (Graduate School of Systems and Information Engineering, University of Tsukuba)

キーワード: 複素，フィルタ，アナログ，受動，圧電トランス　　complex，filter，analog，passive，piezoelectric transformer

要約(英語): In this paper, two passive complex coefficient filters using piezoelectric transformers are proposed. The proposed frequency transformation is specialized for a complex coefficient filter using piezoelectric transformers. By applying the frequency transformation to a real first-order lowpass filter, we can obtain a first-order complex bandpass filter. The resulting circuit is realized by using a piezoelectric transformer, some reactance elements and terminating resistors. It is confirmed that the proposed circuit has complex bandpass characteristics through computer simulation and experiment. On the other hand, it is difficult to design higher order filters, because the circuit does not have the imaginary output. However, by allowing to use of a tight coupling transformer, a second-order complex bandpass filter can be obtained by using the proposed frequency transformation. The resulting circuit is realized by using two piezoelectric transformers, two tight coupling transformers, some reactance elements and terminating resistors. It is also confirmed that the proposed circuit has complex bandpass characteristics through computer simulation and experiment.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.139 No.1 （2019） 特集：電子回路関連技術

本誌掲載ページ: 29-35 p

原稿種別: 論文／日本語
