フリップ・フロップ型90°移相器を適用したデュアルLOスイッチング型直交変調器の設計

フリップ・フロップ型90°移相器を適用したデュアルLOスイッチング型直交変調器の設計

通常価格 ¥550 JPY
通常価格 セール価格 ¥550 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2019/01/01

タイトル(英語): Design of a Dual-LO Switching Quadrature Modulator Using a Flip-Flop Phase-Shifter

著者名: 高良 聡(会津大学 コンピュータ理工学研究科),束原 恒夫(会津大学 コンピュータ理工学研究科)

著者名(英語): Satoshi Takara (Computer Science and Engineering, University of Aizu), Tsuneo Tsukahara (Computer Science and Engineering, University of Aizu)

キーワード: 直交振幅変調,直交変調器,位相誤差,振幅誤差,分周器,移相器  QAM,quadrature modulator,phase error,amplitude error,frequency divider,phase shifter

要約(英語): In recent years, the number of mobile wireless devices that use the modulation such as QAM is increased, and it requires high-precision quadrature modulators and low-cost circuits composed of CMOS devices. In this paper, we propose a quadrature modulator, composed of a newly configured quadrature mixer with function to correct the phase error of LO signal, a flip-flop frequency divider for quadrature LO generation, and an RC-polyphase filter for delay correction. Moreover, we reveal that this circuit has compensation mechanism for the duty-cycle-error of the frequency-doubled-LO (2LO) input signal.

本誌: 電気学会論文誌C(電子・情報・システム部門誌) Vol.139 No.1 (2019) 特集:電子回路関連技術

本誌掲載ページ: 87-88 p
