ミリ波複素誘電率高精度評価法を用いたFDM型3Dプリンタ製熱可塑性樹脂基板の基礎検討

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2021/02/01

タイトル(英語): Study on Thermoplastic Resin Plates Outputted by a FDM Type 3D Printer Using a High Precision Complex Permittivity Measurement Method in Millimeter Wave Region

著者名: 清水　隆志（宇都宮大学 工学部），高萩　耕平（宇都宮大学 大学院工学研究科），古神　義則（宇都宮大学 工学部）

著者名(英語): Takashi Shimizu (School of Engineering, Utsunomiya University), Kohei Takahagi (Graduate School of Engineering, Utsunomiya University), Yoshinori Kogami (School of Engineering, Utsunomiya University)

キーワード: 熱可塑性樹脂，複素誘電率，3Dプリンタ，円筒空洞共振器法，ミリ波_x000D_　　Thermoplastic resin，complex permittivity，3D printer，circular empty cavity resonator，millimeter wave

要約(英語): The era of Internet of Things (IoT) utilizing a large number of wireless sensors is approaching. Such microwave and millimeter wave IoT devices are required not only to have high performance and reliability, but also to have a low cost, variety products and quick developments. Realization of the planer type circuits with an FDM type 3D printer is one of a solution to meet these requirements. In the FDM type, the internal structure of the printed product can be changed easily by printer settings. That mean the complex permittivity of a 3D printed substrate will be able to controlled arbitrarily by RF designer. In this paper, the printing conditions and the complex permittivity of a thin thermoplastic ABS resin substrate for the FDM type 3D printer are studied using the TE011 mode cylindrical cavity resonator method in the 36 GHz band. It is clarified that the relative deviation of the complex permittivity is about 1.5%, and the effective complex permittivity is decreased by the surface unevenness caused by the FDM method. We expect the results can be useful to develop low cost and rapid realization of wireless devices with AM technology for next generation sustainable society.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.141 No.2 （2021） 特集I：IoT社会の進歩を促進するワイヤレス技術　　特集Ⅱ：ディジタル信号処理のためのシステム技術

本誌掲載ページ: 105-110 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/141/2/141_105/_article/-char/ja/
