グリッド電極構造を用いた微小物体の静電的マニピュレーションにおける電極突起の効果

カテゴリ: 論文誌(論文単位)

グループ名: 【C】電子・情報・システム部門

発行日: 2024/11/01

タイトル(英語): Effect of Electrode Protrusions on Micro Object Manipulation using Grid Electrode Structure

著者名: 鈴木　皓太（大阪工業大学大学院 工学研究科 電気電子・機械工学専攻），吉田　恵一郎（大阪工業大学 工学部 電気電子システム工学科）

著者名(英語): Kota Suzuki (Graduate Course in Electrical, Electronic and Mechanical Engineering, Osaka Institute of Technology), Keiichiro Yoshida (Department of Electrical and Electronic Systems Engineering, Osaka Institute of Technology)

キーワード: マイクロプラスチック，プラスチックリサイクル，選別，マニピュレーション，静電気力，誘電泳動力　　micro plastic，plastic recycle，plastic sorting，manipulation，electrostatic force，dielectrophoretic force

要約(英語): A novel technique that manipulates tiny objects using electrostatic forces is proposed. This technique, which has grid-structure electrodes, potentially can drive multiple objects individually. One of the possible applications is precise sorting of small plastic pieces by materials or colors. The dielectrophoretic force that is generated by concentrated electric field is mainly utilized in this technique. In this study, the effect of a protrusion attached at the cross-point of the grid was investigated using a single-cross device which is a basic structure of this technique. A glass sphere with approximately 1.2 mm diameter was used as a model for target objects. The driving force exerted on the target was determined with high-speed photography of the trajectories, along with numerical simulation. It was elucidated that the electric field concentrated by the protrusion enhanced the forces directing to the cross point. At the same time, the comparison with the simulation of the dielectrophoretic force and the calculation of the field strength suggested that a little amount of charge generated by discharge affected the driving force. Moreover, the transfer of the glass sphere between two cross-points with the interval of 2 mm in approximately 300 ms was successful.

本誌: 電気学会論文誌C（電子・情報・システム部門誌） Vol.144 No.11 （2024） 特集Ⅰ：電気関係学会関西連合大会　特集Ⅱ：電子材料関連技術の最近の進展

本誌掲載ページ: 1052-1058 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejeiss/144/11/144_1052/_article/-char/ja/
