無誘導型電流センサの開発とスポット溶接電流の制御

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2012/01/01

タイトル(英語): Development of an Induction-Free Current Sensor for Application in Spot-Welding Current Control

著者名: 高崎　佳明（福岡工業大学情報工学部情報システム工学科），宗貞　辰徳（近畿大学産業理工学部電気通信工学科），園田　敏勝（近畿大学産業理工学部電気通信工学科）

著者名(英語): Yoshiaki Takasaki (Department of Information and Systems Engineering, Faculty of Information Engineering, Fukuoka Institute of Technology), Tatsunori Munesada (School of Humanity-Oriented Science and Engineering, Department of Electrical and Communication Engineering, Kinki University), Toshikatsu Sonoda (School of Humanity-Oriented Science and Engineering, Department of Electrical and Communication Engineering, Kinki University)

キーワード: RI降下型電流センサ，無誘導化，ホール素子型電流センサ，変圧器起電力，検出精度，インバータ電源，溶接電流　　RI drop type current sensor，non-inductive operation，Hall element type current sensor，transformer electromotive force，detection accuracy，inverter power supply，welding current

要約(英語): The authors investigated the control of welding current with a frequency-controlled inverter power supply. Welding current control requires precision sensing of the inverter current, which can reach 10kA. The current transformers and Hall effect devices commonly used in the industry do not deliver the desired performance. The authors investigated the use of a shunt-type current sensor based on the simplest RI drop method for current detection. This paper discusses the investigation of the extent to which sensor inductance can be cancelled out when using the shunt-type current sensor. Experimental results indicate that the inductance component can be cancelled out, thus making non-inductive operation possible. A current sensor has been prototyped and used in a frequency-controlled inverter power supply, demonstrating that welding current control is possible.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.132 No.1 （2012） 特集：半導体電力変換研究会

本誌掲載ページ: 58-66 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/132/1/132_1_58/_article/-char/ja/
