剛体電車線の凹凸とその低減手法

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2012/02/01

タイトル(英語): Unevenness of Sliding Surface of Overhead Rigid Conductor Lines and Method for Reducing Unevenness

著者名: 網干　光雄（（公財）鉄道総合技術研究所），清水　政利（（公財）鉄道総合技術研究所）

著者名(英語): Mitsuo Aboshi (Railway Technical Research Institute), Masashi Shimizu (Railway Technical Research Institute)

キーワード: 電気鉄道，架空電車線，集電，剛体電車線，凹凸　　electric railway，overhead contact line，current collection，overhead rigid conductor line，unevenness

要約(英語): Rigid conductor lines are used in many subways, because the use of such conductor lines reduces the risk of accidents and because less space is required for their installation. However, as the unevenness of the sliding surface of the rigid conductor lines significantly influences the fluctuations in the contact force between pantographs and contact lines, it is necessary to decrease the unevenness at the construction as well as the maintenance stages. In order to investigate the installation accuracy of overhead rigid conductor lines, we have developed a device that accurately and continuously measures the unevenness of the sliding surface. By using this measuring device, we have confirmed that the unevenness of the sliding surface depends on various factors such as the sag between the support points, the deformation of the aluminum base or the conductive rail in the case of a long wavelength, the slight sagging unevenness between the bolts of the long ear, the undulating wear etc. This paper describes the actual unevenness conditions and the technical methods for decreasing the unevenness of the sliding surface of overhead rigid conductor lines.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.132 No.2 （2012） 特集：J-RAIL 2010

本誌掲載ページ: 148-154 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/132/2/132_2_148/_article/-char/ja/
