巻線コイルに圧縮成形を適用した低渦電流損失地上コイルの開発

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2012/02/01

タイトル(英語): Development of Ground Coils with Low Eddy Current Loss by Applying the Compression Molding Method after the Coil Winding

著者名: 鈴木　正夫（（公財）鉄道総合技術研究所），饗庭　雅之（（公財）鉄道総合技術研究所），高橋　紀之（（公財）鉄道総合技術研究所），太田　聡（（公財）鉄道総合技術研究所），岡田　重紀（タカオカ化成工業（株））

著者名(英語): Masao Suzuki (Railway Technical Research Institute), Masayuki Aiba (Railway Technical Research Institute), Noriyuki Takahashi (Railway Technical Research Institute), Satoru Ota (Railway Technical Research Institute), Shigenori Okada (Takaoka Chemical CO., LTD.)

キーワード: 磁気浮上式鉄道，地上コイル，渦電流損失，圧縮成形　　maglev system，ground coil，eddy current loss，compression molding

要約(英語): In a magnetically levitated transportation (MAGLEV) system, a huge number of ground coils will be required because they must be laid for the whole line. Therefore, stable performance and reduced cost are essential requirements for the ground coil development. On the other hand, because the magnetic field changes when the superconducting magnet passes by, an eddy current will be generated in the conductor of the ground coil and will result in energy loss. The loss not only increases the magnetic resistance for the train running but also brings an increase in the ground coil temperature. Therefore, the reduction of the eddy current loss is extremely important. This study examined ground coils in which both the eddy current loss and temperature increase were small. Furthermore, quantitative comparison for the eddy current loss of various magnet wire samples was performed by bench test. On the basis of the comparison, a round twisted wire having low eddy current loss was selected as an effective ground coil material. In addition, the ground coils were manufactured on trial. A favorable outlook to improve the size accuracy of the winding coil and uneven thickness of molded resin was obtained without reducing the insulation strength between the coil layers by applying a compression molding after winding.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.132 No.2 （2012） 特集：J-RAIL 2010

本誌掲載ページ: 185-193 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/132/2/132_2_185/_article/-char/ja/
