入力電流リプルを低減する多相昇圧チョッパの相数と動作モードによる特性比較

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2012/02/01

タイトル(英語): Comparison between Phase Number and Operation Mode of Multiphase Boost Chopper for Reducing Input Current Ripple

著者名: 亨　章弘（長岡技術科学大学），芳賀　仁（長岡技術科学大学），近藤　正示（長岡技術科学大学）

著者名(英語): Akihiro Toru (Nagaoka University of Technology), Hitoshi Haga (Nagaoka University of Technology), Seiji Kondo (Nagaoka University of Technology)

キーワード: 多相昇圧チョッパ，電流連続モード，電流不連続モード，入力電流リプル低減　　multi-phase boost chopper，continuous conduction mode，discontinuous conduction mode，low current ripple

要約(英語): This paper describes characteristics of a multiphase boost chopper on the basis of the difference between its phase number and operation mode. First, this paper presents a theoretical analysis of an input current ripple in a multiphase boost chopper controlled with CCM and DCM. For analysing CCM, the input current ripple in an n-phase boost chopper is expressed by a general formula using a duty ratio. This expression clarifiers integrally the relations between the phase number and input current ripple. The current ripple in CCM is highly reduced than that in DCM for the tested four-phase boost chopper. Furthermore, this paper presents a comparison between the converter efficiency and step response of a four-phase boost chopper controlled in CCM or DCM. The efficiency in CCM is higher than in DCM by 0.5[%]. The phase number affects the step response characteristics in CCM. However, the phase number does not affect the step response characteristics in DCM.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.132 No.2 （2012） 特集：J-RAIL 2010

本誌掲載ページ: 250-257 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/132/2/132_2_250/_article/-char/ja/
