インバータ駆動誘導電動機の非対称性に起因する軸端間電圧の発生メカニズム

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2012/03/01

タイトル(英語): Mechanism of Shaft End-To-End Voltage Generation by Asymmetry in an Inverter-Driven Motor

著者名: 朝倉　祐介（東京工業大学 大学院理工学研究科 電気電子工学専攻），赤木　泰文（東京工業大学 大学院理工学研究科 電気電子工学専攻）

著者名(英語): Yusuke Asakura (Department of Electrical and Electronic Engineering, Tokyo Institute of Technology), Hirofumi Akagi (Department of Electrical and Electronic Engineering, Tokyo Institute of Technology)

キーワード: 軸端間電圧，非対称性，EMI，モータドライブ　　shaft end-to-end voltage，asymmetry，EMI，motor drives

要約(英語): This paper deals with the shaft end-to-end voltage resulting from asymmetric stray capacitances in an inverter-driven motor. The origin of the voltage can be any of the following: a ground leakage current, dielectric breakdown in bearings, and asymmetric stray capacitances on stator windings. The third origin seems to be related to the differential-mode current, but the details of the relationship have not been clarified. In this study, differential-mode tests are carried out on an ungrounded motor rated at 400V and 15kW, and the shaft end-to-end voltage generation by the asymmetric stray capacitances is theoretically discussed. Finaly, a winding model is presented for the purpose of understanding the mechanism responsible for the shaft end-to-end voltage.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.132 No.3 （2012） 特集：産業計測制御全般

本誌掲載ページ: 404-410 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/132/3/132_3_404/_article/-char/ja/
