磁界共振結合を用いた距離センサの提案とその誤差評価

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2012/03/01

タイトル(英語): Proposal and Error Evaluation of Distance Sensor Based on Magnetic Resonance Coupling

著者名: 中村 壮亮（東京大学大学院電気系工学専攻），胡間　遼（東京大学大学院電気系工学専攻），久保田　孝（東京大学大学院電気系工学専攻），橋本　秀紀（中央大学電気電子情報通信工学科）

著者名(英語): Sousuke Nakamura (Department of Electrical Engineering, The University of Tokyo), Ryo Koma (Department of Electrical Engineering, The University of Tokyo), Takashi Kubota (Department of Electrical Engineering, The University of Tokyo), Hideki Hashimoto (Department of Electrical Electronic and Communication Engineering, Chuo University)

キーワード: 距離センサ，磁界共振結合，新しい構成，距離誤差，Q値　　distance sensor，magnetic resonance coupling，novel configuration，distance error，Q factor

要約(英語): The contributions of this study are the proposal of a distance sensor based on magnetic resonance coupling with a novel configuration and error evaluation of the proposed sensor. Since the measuring device and their batteries are connected to the target side in conventional distance sensors based on magnetic resonance coupling, the batteries need to be changed during long-term operation. Therefore, in this paper, a distance sensor that integrates the measuring device into the transmitter side is proposed; in this sensor, external attachments or batteries on the target side are not required. In addition, the distance error in the proposed sensor is evaluated by theory and experiment. In these evaluations, the effect of the Q factor on the relation between the distance error and the distance is the main consideration. Apparently, high-Q-factor antennas can reduce the distance error for long distances but increase the error for short distances. The obtained result can be used as a guideline for designing distance sensors.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.132 No.3 （2012） 特集：産業計測制御全般

本誌掲載ページ: 437-444 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/132/3/132_3_437/_article/-char/ja/
