三相整流器の直流側に現れる商用および倍周波数成分の検討と電気鉄道への影響の評価

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2015/04/01

タイトル(英語): A Study of Commercial Frequency Component and Doubled Component at DC-side of Three-phase Rectifiers and Their Influence on Electric Railways

著者名: 米田　昇平（東京工業大学 大学院理工学研究科 電気電子工学専攻），渡邉　朝紀（東京工業大学 大学院理工学研究科 電気電子工学専攻）

著者名(英語): Shohei Komeda (Department of Electrical and Electronic Engineering, Tokyo Institute of Technology), Tomoki Watanabe (Department of Electrical and Electronic Engineering, Tokyo Institute of Technology)

キーワード: 直流き電方式電気鉄道，三相整流器，帰線電流，軌道回路，電磁両立性　　DC-railway systems，three-phase rectifiers，return current，track circuit，EMC

要約(英語): This paper discusses non-theoretical harmonics at the DC-side of a 12-pulse rectifier in DC railway systems. These harmonics are the commercial frequency component and the doubled component. The cause of these harmonics are (a) diode forward voltage drop difference, (b) transformer secondary inductance difference, (c) voltage harmonics at the AC-side of the rectifier, and (d) effects of the voltage induced by adjacent high-voltage power transmission lines. We evaluated cases (a), (b), and (c), as case (d) has been previously studied(4). The results of the evaluation were as follows:・The effects of both the transformer secondary inductance difference and the voltage harmonics inside the electric power system are not negligible in some cases on the discussion of the EMC problem among railway equipments.・If there are several traction circuits in parallel each of which consists of an input filter, an inverter and several traction motors, the harmonic reduction effect of the filters weakens significantly.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.135 No.4 （2015） 特集：J-RAIL 2013

本誌掲載ページ: 376-385 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/135/4/135_376/_article/-char/ja/
