MEMS-LSI集積化デバイスを用いた触覚センサネットワークシステム開発のための模擬ネットワークシステムの試作

MEMS-LSI集積化デバイスを用いた触覚センサネットワークシステム開発のための模擬ネットワークシステムの試作

通常価格 ¥770 JPY
通常価格 セール価格 ¥770 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【E】センサ・マイクロマシン部門

発行日: 2012/09/01

タイトル(英語): A Simulated Network System Prototype for Development of a Networked Tactile Sensor System with Integrated MEMS-LSI Tactile Sensors

著者名: 中野 芳宏(東北大学 江刺・田中(秀)研究室),室山 真徳(東北大学 江刺・田中(秀)研究室),巻幡 光俊(東北大学 江刺・田中(秀)研究室),田中 秀治(東北大学 江刺・田中(秀)研究室),松崎 栄(東北大学 江刺・田中(秀)研究室),山田 整(トヨタ自動車(株)パートナーロボット部),中山 貴裕(トヨタ自動車(株)パートナーロボット部),山口 宇唯(トヨタ自動車(株)パートナーロボット部),野々村 裕((株)豊田中央研究所 パワーエレクトロニクス研究部),藤吉 基弘((株)豊田中央研究所 パワーエレク

著者名(英語): Yoshihiro Nakano (Esashi and Tanaka Labs., Tohoku University), Masanori Muroyama (Esashi and Tanaka Labs., Tohoku University), Mitsutoshi Makihata (Esashi and Tanaka Labs., Tohoku University), Shuji Tanaka (Esashi and Tanaka Labs., Tohoku University), Sakae Matsuzaki (Esashi and Tanaka Labs., Tohoku University), Hitoshi Yamada (Partner Robot Div, Toyota Motor Corporation), Takahiro Nakayama (Partner Robot Div, Toyota Motor Corporation), Ui Yamaguchi (Partner Robot Div, Toyota Motor Corporation), Yutaka Nonomura (Power Electronics Research Div., TOYOTA CRDL, INC.), Motohiro Fujiyoshi (Power Electronics Research Div., TOYOTA CRDL, INC.), Masayoshi Esashi (Esashi and Tanaka Labs., Tohoku University)

キーワード: 集積化MEMS,触覚センサ,センサネットワーク  Integrated MEMS,Tactile Sensor,Sensor Network

要約(英語): We have developed a tactile sensor network system, which consists of integrated MEMS-LSI tactile sensors (sensor nodes), relay nodes, a host and flexible bus power/interconnection lines for mounting a large amount of tactile sensor elements on the whole body of robots. Each sensor node, which is connected on the common bus lines, transmits sensing data independently to the relay node on the bus when exceeding a predefined sensing threshold value. There are system-level issues such as a threshold value choice for sensing data transmission and a throughput control considering data collision on the bus line. Before fabricating the integrated MEMS-LSI sensor devices, performance of the whole system should be estimated, because to fabricate the integrate devices is expensive. In this paper, we report a less costly simulated network system for resolving the issues without the integrated devices. The simulated system uses easily-available components such as discreet sensors, FPGAs (Field Programmable Gate Array) and a PC. In the system, we implemented sensor node monitoring circuits to analyze network characteristics precisely. The circuits cannot be implemented in the real integrated devices and systems. By using this simulated system, we analyzed data collisions and average transmission delay time. The experimental results show that in the case of 20 sensors pressed with strong forces simultaneously the data collision rate is about 44% when the transmission rate is 1Mbps and about 0.7% when the transmission rate is 10Mbps, respectively. We found that when more sensor nodes transmit their data on the bus simultaneously and/or the transmission rate is lower than several Mbps, each sensor node should control the network traffic for avoiding the collisions with a more smart control mechanism than a simple mechanism we applied.

本誌: 電気学会論文誌E(センサ・マイクロマシン部門誌) Vol.132 No.9 (2012)

本誌掲載ページ: 288-295 p

原稿種別: 論文/日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejsmas/132/9/132_288/_article/-char/ja/
