低電圧CMOSインバータ型差動増幅回路の特性評価

低電圧CMOSインバータ型差動増幅回路の特性評価

通常価格 ¥550 JPY
通常価格 セール価格 ¥550 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【E】センサ・マイクロマシン部門

発行日: 2012/09/01

タイトル(英語): Measurement of Low-Voltage CMOS Inverter-Based Differential Amplifier

著者名: 堀下 祐輔(慶應義塾大学理工学部物理情報工学科),松本 佳宣(慶應義塾大学理工学部物理情報工学科)

著者名(英語): Yusuke Horishita (Faculty of Science and Technology, Department of Applied Physics and Physico-informatics, Keio University), Yoshinori Matsumoto (Faculty of Science and Technology, Department of Applied Physics and Physico-informatics, Keio University)

キーワード: 低電圧増幅器,CMOSインバータ,ネステッドミラー補償,アナログ集積回路  low-voltage amplifier,CMOS inverter,nested miller compensation,analog integrated circuit

要約(英語): In this study, the prototype of CMOS Inverter-Based Differential Amplifier has been developed with ROHM 0.18 mm standard CMOS process. In order to get high DC gain, Nauta’s operational transconductance amplifier (OTA) is adopted as the amplifier stage and nested miller compensation is selected as the phase compensation. The measurement results indicate that power consumption is 18µW, DC Gain is 71dB, input offset voltage is 1.2mV, CMRR is 57dB and PSRR is 83dB at the supply voltage VDD=1V.

本誌: 電気学会論文誌E(センサ・マイクロマシン部門誌) Vol.132 No.9 (2012)

本誌掲載ページ: 316-317 p

原稿種別: 研究開発レター/日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejsmas/132/9/132_316/_article/-char/ja/
