Fabrication of Tactile Display Mechanism Using Arrayed SMA Thick Film Actuator and Si TSV Layer with Individually Connecting Diode

Fabrication of Tactile Display Mechanism Using Arrayed SMA Thick Film Actuator and Si TSV Layer with Individually Connecting Diode

通常価格 ¥770 JPY
通常価格 セール価格 ¥770 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【E】センサ・マイクロマシン部門

発行日: 2021/07/01

タイトル(英語): Fabrication of Tactile Display Mechanism Using Arrayed SMA Thick Film Actuator and Si TSV Layer with Individually Connecting Diode

著者名: Ryo Saito (Graduate School of Science and Engineering, Yamagata University), Yusuke Kimura (Graduate School of Science and Engineering, Yamagata University), Jiale Xu (Graduate School of Science and Engineering, Yamagata University), Takashi Mineta (Gradu

著者名(英語): Ryo Saito (Graduate School of Science and Engineering, Yamagata University), Yusuke Kimura (Graduate School of Science and Engineering, Yamagata University), Jiale Xu (Graduate School of Science and Engineering, Yamagata University), Takashi Mineta (Gradu

キーワード: tactile display,through-substrate via,shape memory alloy,diode,SU-8 bonding

要約(英語): This paper describes the fabrication of a tactile display with a shape memory alloy (SMA) thick film actuator array bonded to an Si substrate using through-substrate-via (TSV) electrodes and diode elements to realize individual connection without reverse current flow. The SMA actuator array (5×5 array, 2 mm pitch) was fabricated from a flash-evaporated SMA thick film while the TSV substrate was fabricated using a different Si substrate. After large through holes and cavities were etched for the vibrating SMA actuator, the TSV electrodes were formed by double-side sputtering and lift-off processes. The fabricated diode element exhibited a sufficient backward breakdown voltage above 36 V and low forward resistance of 15 Ω. On the fabricated SMA and TSV substrates with through holes, 10-μm and 5-μm-thick SU-8 patterns were uniformly formed, respectively, and then, the substrates were bonded using the patterned SU-8 layers with a bonding strength above 3.5 MPa. Simultaneously, in the bonding process, the electrodes on the SMA and TSV substrates were electrically connected via an Ag paste dispensed in the opening of the SU-8 pattern. Using the proposed processes, we successfully completed the tactile display mechanism with the arrayed SMA actuator , including the TSV substrate with diode elements.

本誌: 電気学会論文誌E(センサ・マイクロマシン部門誌) Vol.141 No.7 (2021) 特集:第37回「センサ・マイクロマシンと応用システム」シンポジウム受賞論文

本誌掲載ページ: 260-264 p

原稿種別: 論文/英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejsmas/141/7/141_260/_article/-char/ja/
