超高周波水晶振動子の周波数特性測定に関する一検討

カテゴリ: 論文誌(論文単位)

グループ名: 【A】基礎・材料・共通部門

発行日: 2012/10/01

タイトル(英語): A Study on Measurement of Frequency Characteristics of the Super-high Frequency Crystal Resonator

著者名: 作田　幸憲(日本大学理工学部電子情報工学科)，渡邉　充紘(日本大学大学院理工学研究科情報科学専攻)，今池　健(日本大学理工学部電子情報工学科)，関根　好文(日本大学理工学部電子情報工学科)

著者名(英語): Yukinori Sakuta (Department of Electronics & Computer Science, College of Science and Technology, Nihon University), Mitsuhiro Watanabe (Program in Computer Science, Graduate School of Science & Technology, Nihon University), Takeshi Imaike (Department of Electronics & Computer Science, College of Science and Technology, Nihon University), Yoshifumi Sekine (Department of Electronics & Computer Science, College of Science and Technology, Nihon University)

キーワード: 超高周波水晶振動子，周波数特性測定，マイクロストリップライン，分布定数解析　　super-high frequency crystal resonator，frequency characteristics，microstrip line，distribution network analysis

要約(英語): The progress of the fabrication technology of the crystal resonators became to expand to VHF and UHF band beyond a traditional HF band. Along with this fact, the characteristic of the crystal resonators is demanded to be measured in these frequency bands. An international standardized measurement method, however, do not exist now. In these frequency range, all of devices and circuits work as distributed constant circuit. When we measure the characteristic of the crystal resonator, it is necessary to consider the setting portion of the crystal resonator on circuit as the distributed constant circuit. We have examined the use of the microstrip line to measure the characteristic of the crystal resonator.

本誌: 電気学会論文誌A（基礎・材料・共通部門誌） Vol.132 No.10 （2012） 特集（Ⅰ）：新機能性ナノスケール磁性材料の作製・評価 特集（Ⅱ）：イノベーションを支える最新の計測技術2012

本誌掲載ページ: 871-877 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejfms/132/10/132_871/_article/-char/ja/
