光伝送信号品質評価装置に用いる低ジッタ短光パルス発生器の提案と評価

カテゴリ: 論文誌(論文単位)

グループ名: 【A】基礎・材料・共通部門

発行日: 2012/10/01

タイトル(英語): Proposal for Short Optical Pulse Generator with Low Time Jitter for Monitoring Optical Signal Quality

著者名: 新井　茂雄(アンリツ(株))，大谷　昭仁(アンリツ(株))，野中　弘二(高知工科大学)

著者名(英語): Shigeo Arai (Anritsu Corporation), Akihito Otani (Anritsu Corporation), Koji Nonaka (Kochi University of Technology)

キーワード: 信号品質監視，利得スイッチLD，低ジッタ，短光パルス，ペデスタル　　signal quality monitoring，gain-switched LD，low timing jitter，short optical pulse，pedestal

要約(英語): An optical performance monitor (Q-monitor) based on all-optical sampling technology has been reported as an optical signal quality monitor for photonic networks. The Q-monitor measures the eye pattern of the optical transmission signal, and the signal quality is assessed by calculating the Q factor from the measured eye patterns. Here, we propose a short optical pulse generator with low time jitter as an optical sampling pulse source for the Q-monitor. It consists of an optical pulse source, a pulse compressor, and a waveform shaper. We confirmed that the pedestal-suppressed pulse was obtained using the pulse shaper, and that optimizing the pulse generator operating conditions produced a pulse width of 7.0 ps when the RMS time jitter was less than 0.5 ps. The eye pattern is clear for a 10-Gb/s NRZ signal using a Q-monitor with the short optical pulse generator. This paper explains the pulse generator principle and performance. Furthermore, we report evaluation results for the Q-monitor with pulse generator.

本誌: 電気学会論文誌A（基礎・材料・共通部門誌） Vol.132 No.10 （2012） 特集（Ⅰ）：新機能性ナノスケール磁性材料の作製・評価 特集（Ⅱ）：イノベーションを支える最新の計測技術2012

本誌掲載ページ: 901-906 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejfms/132/10/132_901/_article/-char/ja/
