静止気体中で使用する白金抵抗温度計のための評価方法の検討

カテゴリ: 論文誌(論文単位)

グループ名: 【A】基礎・材料・共通部門

発行日: 2012/10/01

タイトル(英語): Study on an Evaluation Method of Platinum Resistance Thermometers Used in the Stationary Air

著者名: 小平　和明(日本電気計器検定所)

著者名(英語): Kazuaki Kodaira (Japan Electric Meters Inspection Corporation)

キーワード: 温度計測，白金抵抗温度計，自己加熱，比較測定　　temperature measurement，platinum resistance thermometer，self-heating，comparison measurement

要約(英語): An evaluation method of platinum resistance thermometers (PRTs) used in the stationary air was considered. A comparison measurement apparatus to evaluate PRTs was developed by using a commercially available temperature bath and the performance of the apparatus was evaluated. The apparatus has high temperature stability and good temperature distribution although the thermal medium is the air. The uncertainty of the apparatus is less than 1mK. A PRT was evaluated for a trial with this apparatus at 23℃. First, a PRT that was set in the water was measured with a Standard Platinum Resistance Thermometer (SPRT) in the temperature bath. Next, the identical PRT was set in the air chamber of the developed apparatus and measured with the SPRT. And, each result was compared. As a result, it was possible to distinguish the difference of behavior of the PRT at different environment by a proposed method in this study. And, it was confirmed that the cause of different behavior was the self-heating of the PRT.

本誌: 電気学会論文誌A（基礎・材料・共通部門誌） Vol.132 No.10 （2012） 特集（Ⅰ）：新機能性ナノスケール磁性材料の作製・評価 特集（Ⅱ）：イノベーションを支える最新の計測技術2012

本誌掲載ページ: 913-919 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejfms/132/10/132_913/_article/-char/ja/
