特殊な巻装方法によるTwo-stage誘導分圧器

特殊な巻装方法によるTwo-stage誘導分圧器

通常価格 ¥770 JPY
通常価格 セール価格 ¥770 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【A】基礎・材料・共通部門

発行日: 2012/10/01

タイトル(英語): Two-stage Inductive Voltage Divider using Special Winding Method

著者名: 堤 晋太郎(日本電気計器検定所)

著者名(英語): Shintaro Tsutsumi (Japan Electric Meters Inspection Corpotation)

キーワード: 誘導分圧器,Two-stage誘導分圧器,漏れインピーダンス,分圧比  inductive voltage dividers,two-stage inductive voltage dividers,leakage impedance,voltage ratio

要約(英語): Inductive voltage dividers (IVDs) are widely used in the field of AC measurements, such as impedance measurements at audio frequencies. Two-stage guarded IVD has been developed by D N. Homan and T L. Zapf about forty years ago. However, it is not easy to construct the two-stage guarded IVD. Therefore, we have developed a two-stage IVD using special winding method without guard by magnetic and electrical shield. To reduce admittances of each winding wires, corrugated cardboard of polypropylene is used for new two-stage IVD. In addition, ratio winding and excitation winding were wound toroidally around two FINEMET ring cores using PEW flat cable 0.7 mm in diameter. As a result, the in-phase ratio errors are within ±6.1×10-8 of the input at frequency 1kHz or less. In this report, the winding methods and measurement results of new two-stage IVD are described.

本誌: 電気学会論文誌A(基礎・材料・共通部門誌) Vol.132 No.10 (2012) 特集(Ⅰ):新機能性ナノスケール磁性材料の作製・評価 特集(Ⅱ):イノベーションを支える最新の計測技術2012

本誌掲載ページ: 924-929 p

原稿種別: 論文/日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejfms/132/10/132_924/_article/-char/ja/
